产品特点：
1.采用进口新型离心泵，具有高性能、高效率且节省能源，使用寿命长。
2.循环染液流量，根据不同纱缓和染色工艺要求，通过主泵变频控制系统，达到合理流量并节省能耗，实现同步染色控制。
3.采用新颖高效外置式换热器，换热效果好，减少主缸无效空间，减小浴比。
4.采用新型自动液流换向装置，换向时液流不停顿，增加了循环次数，使染色更均匀，同时减少峰值电流消耗，延长电器、设备使用时间。
5.低浴比(1：4-1：6)，节省染料、助剂和能源，减少排污量，提高经济效益。
6.高效的清洗系统，有效节省清洗时间及用水量。
7.快速卸载纱架，卸载快速容易，减轻劳动强度，节省工效。
8.采用先进电脑控制，全自动控制比例加料、进水、排放、升温、恒温、降温及清洗等染色工艺要求，可连中央集控运行。
标准结构：
1.染缸和所有染液接触部分均采用优质、高级、抗腐蚀不锈钢制造。
2.采用新颖高效率不锈钢离心泵。
3.高效外置式热交换器。
4.垂直式缸体：开盖结构有气缸或重锤开关装置，带缸盖安全联锁装置。
5.敞开式加料桶配辅加料系统，平衡(回流)系统。
6.主缸加压装置(全充式)。
7.高精度感测器水位控制系统。
8.配先进微机处理器的主控电箱。
任选件：
1.带直接加热装置的等容量预备缸、输送泵、搅拌系统。
2.各种纱架如：筒子、散毛、绞纱、拉链和经轴等。
3.高温排放。
4.定量渐进加料系统。
5.第二入水和第二排放。
6.减载纱管及其配件。
7.筒子纱染色附件如：纱管、中间垫片及自落锁头等。
Product characteristics:
The imported centrifugal pump has high performance, high efficiency, energy saving and long service life.
According to different softening dyeing process requirements, the circulating dyeing fluid flow rate can be reasonably controlled and energy consumption can be saved by the frequency conversion control system of the main pump.
Adopting novel and high-efficiency external heat exchanger, the heat transfer effict is good , the invalid space of main cylinder is reduced, and the bath ratio is reduced.
Adopting a new type of automatic liquid flow reversing device, the liquid flow will not stop when reversing , increasing the number of cycles, making dyeing more uniform, reducing peak current consumption, and prolonging the use tima of electrical appliances and equipment.
Low bath ratio(1:4-1:6), saving dyes, auxiliaries and energy, reducing pollutant discharge and increasing economic benefits.
Efficent cleaning system, which effectively saves cleaning time and water consumption of yarn rack, easy and fast unloading. reducing labor intensity and saving work efficiency.
Adopt advanced computer control, fullyautomatic control proportional feeding water intake, discharge, heating, constant temperature, cooling and cleaning dyeing process requirements, can be connected with centralized control operation.
Standard structure:
The contact part of dye vat and all dyeing liquor os of high quality and high grade. Corrosion resistant stainless steel.
Adopt new high efficiency stainless steel centrifugal pump. Efficient external heat exchanger. The vertical cylinder block.
The opening structure has a cylinder or a hammer switch device, and a safety interlock device with a cylinder head.
Open type plus barrel plus auxiliary feeding system, balance(reflux) system.
Main cylinder pressurizing device(air cushion type).
Circulating condensing unit(fully charged).
High accuracy sensor level control system.
The main control cabinet equipped with advanced microprocessor.
Optional parts:
An equal capacity reserve cykinder with a direct heating device and adelivery pump. Mixing system. All kinds of gauze frames, such as cheese, loose wool and shark yarn. Zippers and warps.
High temperature discharge.
Quantitative gradual addition system.
Second water entry and second emission.
Reduced load bobbins and accessories.
Cheese dyeing accessories such as bobbins, intermediate gaskets and self falling locks.
